ZF AV 133 - Page 53

16. Use 5873.002.001 [Basic tool] and
5873.012.013 [R
apid grip] to pull both
tapered roller bearings from the output gear.
Fig. 63
17. Pull bearing outer ring (1) with
5870.300.035 [Extr
acting device] out of the
portal housing.
18. Remove shim.
Fig. 64
19. Loosen cylindrical screw.
Fig. 65
Dismantling
EN 4472.751.001 - 2015-11
53
