The connector pin out signal definitions are described as the table
below:
Pin SignalName Pin SignalName
1 (USB1) USB +5 Volt 11 (USB2) USB +5 Volt
2 USB Port 1- 12 USB Port 2-
3 USB Port 1+ 13 USB Port 2+
4 Ground 14 Ground
5 No Connect 15 No Connect
6(PS/2 Mouse)PS/2 Data 16 (IR) +5V
7 PS/2 Clock 17 No Connect
8 Ground 18 Infrared Receive
9 No Connect 19 Ground
10 +5V 20 Infrared Transmit
s 370 CPU SOCKET
The Mainboard provides a 370-pin Socket 370 CPU Socket for
use with Intel Socket 370 Celeron processor. The CPU should
have a fan attached to it to prevent overheating. If a fan is not
present, a fan should be installed prior to turning the system on.
For Software Installation, please refer to the CD-ROM.
