Operations and Power Options
The operations and power options of the S3F8S19 Development Board are listed in
Table 1.
S3F8S19 MCU
Key features of the S3F8S19 MCU include:
• SAM88RC CPU core
• 32K x 8 bits program memory
• 2,086 × 8 bits data memory
• Endurance: 10,000 Erase/Program cycles
• 78 instructions
• 40 normal I/O pins in the 48-pin QFP package
• 8 interrupt levels and 26 interrupt sources
• One programmable 8-bit basic timer (BT) for oscillation stabilization control or watch-
dog timer function
• One 16-bit timer/counter (Timer 0) with Interval mode and PWM mode
Table 1. Operations and Power Options of the S3F8S19 Development Board
Option Operations Jumper Status Power Notes
1 Programming
/Debugging
J18 1-2 ON V
DD
= 3.00 V
V
CC
_T = 2.95 V
USB cable not connected on P1
J21 1-2 OFF J21 should be OFF when
programming
2 Programming
/Debugging
J18 1-2 OFF V
DD
= 3.12 V
V
CC
_T = 3.30 V
USB cable connected on P1
J21 1-2 OFF J21 should be OFF when
programming
3 Programming
/Debugging
J18 1-2 ON V
DD
= 3.30 V
V
CC
_T = 3.30 V
USB cable connected on P1
J21 1-2 OFF J21 should be OFF when
programming
4 Stand-Alone J18 1-2 ON V
DD
= V
CC
_T =
3.30 V
USB cable connected on P1
J21 1-2 Not relevant
