S3F8S19 Development Board
The purpose of the S3F8S19 Development Kit is to provide a set of hardware and software
tools for the development of hardware and firmware for applications based on the
S3F8S19 microcontroller. An image of the S3F8S19 Development Board is shown in
Figure 12; a block diagram is shown in Figure 13.
Figure 12. The S3F8S19 Development Board
Figure 13. S3F8S19 Development Board Block Diagram
