ZiLOG S3F8S19

UM026803-0816 Overview
S3F8S19 Development Kit
User Manual
1
Overview
Zilog’s S3F8S19 Development Kit, part number S3F8S190100ZCOG, allows you to eval-
uate your S3F8S19-based designs and applications. The Kit features a Development
Board consisting of the following components:
• Four LEDs
• Five pushbuttons
• Buzzer/speaker
• LCD module
• UART
This user manual provides instructions for setting up and configuring the S3F8S19 Devel-
opment Board. It includes schematic diagrams and a discussion of the Board features and
ZDS II.
The S3F8S19 Development Board features an S3F8S19 MCU in a 48-pin QFP package,
plus an S3 PGM connector to connect the Board to a host development PC using the S3
Flash In-System Programmer II (ISP). To learn more about the S3F8S19 MCU, refer to
the S3F8S19 Product Specification (PS0312
) and/or the S3 Flash In-System Programmer
User Manual (UM0266
).
This document guides you through the following tasks:
• Downloading and installing ZDS II software and documentation
• Connecting the S3 Flash ISP II and S3F8S19 Development Board to your PC
• Starting the S3F8S19 Ledblink sample program
Kit Contents
The S3F8S19 Development Kit contains the following items:
• S3F8S19 Development Board
• S3 Flash ISP II
• 10-circuit ribbon cable
• USB A (male) to Mini-B USB cable (2)
• S3F8S19 Development Kit hardcopy insert
