Page 36 MS - SOUND decoders MS440 to MS990 and MN - NON-SOUND decoders MN170 to MN340
#433
Swiss Mapping Group 1
“A2” forward
Bits 0 - 3:
1 - 12
14 (FO0f)
15 (FO0r)
Bits 5 - 7:
0 - 7
0
Bits 0 - 3:
Additional function output to be switched ON in forward di-
rection provided that both the “F” and “M”-keys are ON (if
bit #7 for the M-key = 1, otherwise F-key ON is sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
#434
Swiss Mapping Group 1
“A1” reverse
Bits 0 - 3:
1 - 12
14 (FO0f)
15 (FO0r)
Bits 5 - 7:
0 - 7
0
Bits 0 - 3:
Function output to be switched ON in reverse direction pro-
vided that both, the “F” and “M”-keys are ON (if bit #7 for
the M-key = 1, otherwise F-key ON is sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
#435
Swiss Mapping Group 1
“A2” reverse
Bits 0 - 3:
1 - 12
14 (FO0f)
15 (FO0r)
Bits 5 - 7:
0 - 7
0
Bits 0 - 3:
Additional function output to be switched ON in reverse di-
rection provided that both the “F” and “M”-keys are ON (if
bit #7 for the M-key = 1, otherwise F-key ON is sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
#436
- #441
. . . Group 2.
. . .
0
All 6 CVs in group 2 are defined the same way as the 6
CVs in group 1.
#442
- 447
. . . Group 3.
. . .
0
All 6 CVs of the following groups are defined the same way
is the 6 CVs in group 1.
#448
- #453
. . . Group 4.
. . .
0
. . .
#454
- #459
. . . Group 5.
. . .
0
. . .
#460
- #465
. . . Group 6.
. . .
0
. . .
#466
- #471
. . . Group 7.
. . .
0
. . .
#472
- #477
. . . Group 8.
. . .
0
. . .
#478
- #483
. . . Group 9.
. . .
0
. . .
#484
- #489
. . . Group 10.
. . .
0
. . .
#490
- #495
. . . Group 11.
. . .
0
. . .
#496
- #501
. . . Group 12.
. . .
0
. . .
#502
- #507
. . . Group 13.
. . .
0
. . .
#800
- #805
. . . Group 14.
. . .
0
. .
#806
- #811
. . . Group 15.
. . .
0
. . .
#812
- #817
. . . Group 16.
. . .
0
. . .
#818
- #823
. . . Group 17.
. . .
0
. . .
#508
#509
#510
#511
#512
Dimming values for the
“Swiss Mapping”
Special configurations
(0- 31)*8
(Only bits
3 - 7 are
used)
Bits 0 - 2
0
Each group-CV (i.e. #432, #433, #434, #435) can be linked
to one of these five dimming CVs.
This means that the function outputs shall be dimmed ac-
cordingly when switched on.
Value 0 = dark, value 31 = not dimmed.
Usable only with function outputs FO0 to FO13.
Bit 0 = 1: suppresses the lighting effect
Bit 1 = 1: Flashing effect
Bit 2 = 1: Inverted flashing
#399
Speed
dependent high beam
(Rule 17)
0 - 255
0
In combination with the “Swiss Mapping” special high-beam
setting, see CV #431 = 255; applies to all 17 CV-groups
(CV #437, #443, ...):
Switches to high-beam only when the speed exceeds the
value in this CV; based on the decoder’s internal 255 speed
steps.
EXAMPLES and SPECIAL CASES:
= 0: High-beam at any speed (incl. stand-still), controlled
only by the F-key (e.g. as per CV #430).
= 1: High-beam only while driving (not at stand-still), other-
wise controlled by the F-key (e.g. CV #430).
= 128: Switches to high-beam when reaching medium
speed.
