Page 40 MS - SOUND decoders MS440 to MS990 and MN - NON-SOUND decoders MN170 to MN340
“Effects” can be assigned to up to 15 function outputs in total, this is done with
CVs #125, #126, #127 … #132, #159, #160, #195 … #199
for Front light, Rear light, FO1 … FA6, FA7, FA8, FO9 … FO13
The values programmed into those effect CVs consist of
the actual 6-bit - effect - Code and the 2-bit - direction- code
Bits 1,0 = 00: direction independent (always active, effect code without addition)
= 01: only active in forward direction (effect code +1)
= 10: only active in reverse direction (+2)
Each CV #125, #126, …
Bits 7 … 2 = 000000xx no effect, only direction = (0), 1, 2
= 000001xx Mars light + direction = 4, 5, 6
= 000010xx Random flicker (e.g. charcoil flickering) + direction = 8, 9, 10
= 000011xx Flashing headlight + direction = 12, 13, 14
= 000100xx Single pulse strobe + direction = 16, 17, 18
= 000101xx Double pulse strobe + direction = 20, 21, 22
= 000110xx Rotary beacon simulator + direction = 24, 25, 26
= 000111xx Gyralite + direction = 28, 29, 30
= 001000xx Ditch light type 1, right + direction = 32, 33, 34
= 001001xx Ditch light type 1, left + direction = 36, 37, 38
= 001000xx Ditch light type 2, right + direction = 40, 41, 42
= 001001xx Ditch light type 2, left + direction = 44, 45, 46
= 001100xx Uncoupler: time/voltage threshold = 48, 49, 50
in CV #115, automatic disengagement in CV #116
= 001101xx “Soft start” = slow brightening up of function output = 52, 53, 54
= 001110xx Automatic stoplights for trams, delay at standstill variable,
Stoplight-off delay see CV #63. = 56, 57, 58
= 001111xx Function output turns itself off at speed > 0
(i.e. turns off cab light when driving) = 60, 61, 62.
= 010000xx Automatic output turns itself off automatically after 5 minutes = 64, 65, 66
(i.e. to protect smoke generators form overheating).
= 010001xx As above, but after 10 minutes = 68, 69, 70
= 010010xx Speed or load dependent smoke generation = 72, 73, 74
for STEAM locos according to CVs #137 - #139 (heating during standstill, heavy smoke at
high speed or load). Automatic turn-off, as per CV #353;
after turn-off only available by reactivating the function.
= 010100xx Driving state-dependent smoke generation for diesel = 80, 81, 82
engines according to CVs #137 - #139 (heating during standstill, heavy smoke
during motor start-up sound and acceleration). Synchronized
control of fan connected to the fan output.
Smoke turns off automatically as per CV #353; function key must be pressed to reactivate
smoke.
= 010110xx slow brightening up & slow dimming of a = 88, 89, 90
function output; useful for various lighting effects or
motor-controlled consumers (e.g. for fans or snow blower-wheels).
Dimming and brightening up times in CVs #190, #191!
= 011000xx sparks with heavy braking = 96, 97, 98
= 011010xx Dimming - Setting the dimming value in CV #192 = 104, 105, 106
- Effect CVs without effect (effect code 000000) produce direction dependent function outputs
EXAMPLE: CV #127 = 1, CV #128 = 2, CV #35 = 12: FO1, FO2 operate directional, ON/OFF with F1 key.
Note regarding ditch lights: those are only active, if the headlights (F0) and function F2 are turned on; this corresponds to the American prototype. The ditch lights
will only be working if the applicable bits in CV #33 and #34 are on (the definition in CV #125 - #128 in itself is not enough but a necessary addition). Example: If
ditch lights are defined for FO1 and FO2, the bits 2 and 3 in CV #33 and 34 have to be set accordingly (i.e. CV #33 = 13 (00001101), CV #34 = 14 (00001110).
Bits 1, 0 = 00: bidirectional (active in both directions)
= 01: only active in forward direction
= 10: only active in reverse direction
American
Lighting effects, and
other effects,
Couplings, smoke genera-
tors, etc.
on the function output
“Front light”,
Configurations and
Modifications
of the effects by
CVs #62, #63, #64, and
CV #115, #116
(for coupler).
ATTENTION in case of CV #125 and #126: change
CVs #33, #34.... if direction is wrong!
Bits 7, 6, 5, 4, 3, 2 = Effect-Code
EXAMPLES (Effect - value programmed into CV #125)
Mars light forward only - 00000101 = 5
Gyralite independent of direction - 00011100 = 28
Ditch type 1 left, only forward - 00100101 = 37
Uncoupler - 00110000 = 48
Soft start of output - 00110100 = 52
Autom. brake light - 00111000 = 56
Autom. Cab light OFF - 00111100 = 60
Speed/load depen. smoke - 01001000 = 72
Speed/load dependency diesel smoke - 01010000 = 80
Effects on function output
rear light
See CV #125 for details
#125 → Front headlight
#126 → Rear headlight
Effects on FO1, FO2,
FO3, FO4, FO5, FO6
See CV #125 #127 → FO1 #128 → FO2 #129 →
FO3 #130 → FO4 #131 → FO5 #132 → FO6
like CV #125 #159 → FO7 #160 → FO8
Effects on FO9, FO10,
FO11, FO12, FO13
like CV #125 #195 → FO9 #196 → FO10
#197 → FO11 #198 → FO12 #199 → FO13
Brake light (code 001110xx in CV #125ff): Afterglow in
tenths of a second (i.e. range 0 to 25 sec) at standstill
after stopping
Modifications
of lighting effects
Tens digit: Changing cycle time
for various effects (0 - 9, default 5), or
brighting up at soft start at 001101 (0 - 0.9 sec)
Ones digit: Extends off-time
Bit 7 - 4: define a ditch light key (function key+1)*16
consequent: 0=F2, 1=F0, 2=F1,.. 15=F14
Bit 3 - 0: Ditch light OFF time modification [s]
Bit 0 = 1: Activate ditch light if bell is played
Bit 1 = 1: Activate ditch light if horn is played
Brighting-up time
for effects 88, 89 and 90
The range 0 – 100 equals 0 – 1 sec (10ms/value)
101 – 200 1 – 100s (1s/Wert)
201 – 255 100 – 320s (4s/Wert)
Dimming time
for effects 88, 89 and 90
The range 0 – 100 equals 0 – 1 sec (10ms/value)
101 – 200 1 – 100s (1s/Wert)
201 – 255 100 – 320s (4s/Wert)
Code 011010xx in CV #125ff: Decreases the brightness of the
(light) function output by the set value (in percent). (e.g. value
127 = 50 %)
Automatic
turn-off of the
smoke generator
For effects “010010xx” or “010100xx” (smoke generator): over-
heating protection: Turn-off ½ min to 2h.
= 0: no automated shut-down
= 1 to 255: automatic turn-off after 25sec/unit
To Next Page
