Page 2 Non-Sound Decoder MX618 - MX638 and Sound Decoder MX640 - MX659
1 Overview
These decoders are suitable for N, HOe, HOm, TT, HO, OO, Om and O gauge engines.
They operate in the NMRA-DCC data format as well as the MOTOROLA protocol, in DC analog
mode with DC power packs (including PWM) and with AC analog (Märklin Transformers with over-
voltage pulses for direction change. Exception: MX621 and MX640)).
25 x 11 x 2 mm Non-Sound - 0.8 A - 4 Fu-Outputs – DCC and DC
“Thin decoder“, single layer board, especially low priced
NOTE to Typ MX600P12 (with PluX-12 interface):
the dimensions of this design do NOT correspond to the PluX standard.
MX600 plug configurations:
9 wires (120mm long) for power pick-up, motor and 4 function outputs.
MX600, with 8-pin plug as per NEM652 on 70mm wires.
As MX600, with 12 pin PluX connector mounted on circuit board.
8 x 8 x 2.4 mm Non-Sound - 0,7 A - 6 Fu-Outputs -- DCC, MM and DC
Subminiature-Decoders, with reduced. Fu Mapping ZIMO characteristics;
TYPICAL APPLICATION: vehicles in N, H0e, H0m.
MX616 plug configurations:
7 wires for power pick-up, motor, 2 function outputs (120 mm). 4 more function
outputs on solder pads.
As MX616, with 6-pin plug as per NEM651, mounted on the circuit board.
As MX616, with 8-pin plug as per NEM652 on 70mm wires.
13 x 9 x 2.6 mm Non-Sound - 0,7 A - 6 Fu-Outputs -- DCC, MM and DC
Subminiature-Decoder, with reduced Fu Mapping ZIMO characteristics;
TYPICAL APPLICATION: Vehicles in N, H0e, H0m.
MX617 plug configurations:
MX617
MX617N
MX617R
MX617F
7 wires for power pick-up, motor, 2 function outputs (120 mm). 4 more function
outputs on solder pads.
As MX617, with 6-pin plug as per NEM651, mounted on the circuit board..
As MX617, with 8-pin plug as per NEM652 on 70mm wires
As MX617, with 6-pin plug as per NEM651 on 70mm wires.
15 x 9.5 x 2.8 mm Non-Sound - 0.7 A - 4 Fu-Outputs + 2 logic level – SUSI - DCC, MM, DC, AC
Next 18 – Decoder (“Railcommunity” Interface-Standard RCN-118)
MX620 Out of production since June of 2010; replaced by MX621 and MX622.
12 x 8.5 x 2.2 mm Non-Sound - 0.7 A DCC and DC-Analog (not for MOTOROLA)
Sub-miniature Decoder, with reduced ZIMO features.
TYPCIAL APPLICATION: Vehicles in N, HOe and HOm.
MX621 plug configurations:
7 wires (120mm long) for power pick-up, motor and 2 function outputs. Two
more function outputs on solder pads.
MX621 with 6-pin plug as per NEM651, mounted on the circuit board.
MX621 with 8-pin plug as per NEM652 on 70mm wires.
MX621 with 6-pin plug as per NEM651 on 70mm wires.
14 x 9 x 2.5 mm Non-Sound - 0.8A - 6 Fu-Outputs - 2 Servos - SUSI DCC, MM, DC, AC
Miniature-Decoder, with all ZIMO features.
TYPCIAL APPLICATION: N, HOe, HOm; and HO vehicles with limited space.
MX622 plug configurations:
7 wires (120mm long) for power pick-up, motor and 2 function outputs. Two
more function outputs on solder pads.
MX622 with 8-pin plug as per NEM652 on 70mm wires.
MX622 with 6-pin plug as per NEM651 on 70mm wires.
MX622 with 6-pin plug as per NEM651, mounted on circuit board.
20 x 8.5 x 3.5 mm Non-Sound - 0.8 A - 4 Fu-Outputs - 2 Servos - SUSI DCC, MM, DC, AC
Small Decoder; built especially narrow for universal applications in tight spac-
es.
TYPICAL APPLICATION: HO and TT... Due to excellent dielectric strength
(50V), it is also suitable for AC analog with the old Märklin transformer.
MX623 plug configurations:
MX623
MX623R
MX623F
MX623P12
9 highly flexible wires (120mm) for pick-up, motor and 2 function outputs. Solder
pads for 4 additional logic level outputs, two of them as servo outputs or SUSI.
MX623 with 8-pin plug as per NEM652 on 70mm wires.
MX623 with 6-pin plug as per NEM651 on 70mm wires.
MX623 with 12 pin PluX connector, mounted on circuit board.
