ZIMO MX659N18 - CV Summary and Service Information; CV Summary List

Non-Sound Decoder MX600 - MX638 and Sound Decoder MX640 - MX659 Page 71
11 CV – Summary List
This list summarizes all CV's in numerical order, with very short descriptions (as a reminder). De-
tailed information can be found in the preceding chapters ("Configure", "ZIMO Sound").
The “red” column: Denotes the chapter the CV’s belong to.
Chap-
ter
CV
Denomination
Range
Default
Description
3.4
#1
Short address
1 – 127
3
The “short” (1-byte) loco address.
3.6
#2
Start voltage
1 - 255
1
Internal speed step applied as lowest external speed
3.7
#3
Acceleration rate
0 - 255
(2)
Multiplied by 0.9 equals’ acceleration time.
3.7
#4
Deceleration rate
0 - 255
(1)
Multiplied by 0.9 equals’ deceleration time.
3.6
#5
Top speed
0 - 255
1 (=255)
Internal speed step for highest external speed step.
3.6
#6
Medium speed
0 - 255
1
(=1/3 of #5)
Internal speed step for medium external speed step
3.3
#7
SW-Version
Number
Read only
-
Current firmware version number. For subversion see
CV #65.
3.3
#8
Manufacturer ID,
Reset &Set
Read only
145 (=ZIMO)
Given by the NMRA. CV #8=8: Hard Reset.
3.6
#9
Motor control
frequency
1 - 255
55
Tens digit for sampling rate, ones digit for sampling
time.
3.6
#10
Compensation
0 - 252
0
Internal speed step for reduced intensity per CV #113.
-
#11
------
-
#12
------
3.5
#13
Analog functions
F1…F8
0 - 255
0
Select analog functions F1 (Bit 0), F2 (Bit 1)…
3.5
#14
Analog functions F0,
F9…
0 - 255
0
Select analog functions F0 forw (Bit 0), rev (Bit 1)…
-
#15
------
-
#16
------
3.4
#17,
18
Extended Address
128 -10239
0
The "long" (2-byte) addresses. Active only if Bit 5 in CV
#29 is set to 1.
3.4
#19
Consist address
0 – 127
0
Consist address for 2 or more engines, valid if >0
3.4
#21
Consist function F1 -
F8
0 - 255
0
Consist functions F1 (Bit 0), F2 (Bit 1)…
3.4
#22
Consist function F0
0 - 191
0
Select consist functions F0 forw (Bit 0), rev (Bit 1)…
3.7
#23
Acceleration
variation
0 - 255
0
Temporary adaptation of CV #3 (Acceleration).
3.7
#24
Deceleration
variation
0 - 255
0
Temporary adaptation of CV #4 (Deceleration).
Chap-
ter
CV
Denomination
Range
Default
Description
-
#25
------
-
#26
------
3.10
#27
Asymmetrical stops
(ABC)
0, 1, 2, 3
0
Bit 0 = 1: Stops if voltage in right rail, Bit 1 = 1: left rail
3.2
#28
RailCom
Configuration
0 - 3
3
Bit 0 = 1: RailCom (Broadcast), Bit 1 = 1:RailCom Data
3.2
#29
Basic settings
0 - 63
14 =
0000 1110
Bit 3 = 1
(“RailCom”
is switched
on)
Bit 0 - Train direction: 0 = normal, 1 = reversed
Bit 1 - Speed steps: 0 = 14, 1 = 28
Bit 2 - DC (analog): 0 = disabled, 1 = enabled
Bit 3 – RailCom: 0 = deactivated, 1 = activated
Bit 4 - Speed table: 0 = 3-point, 1 = 28-point
Bit 5 - Decoder address:0 = CV #1, 1 = CV #17+18
3.14
#33
NMRA Function map
F0
0 - 255
1
Function mapping for F0 forward
3.14
#34
NMRA Function map
F0
0 - 255
2
Function mapping for F0 reverse
3.14
#35-
46
Function mapp. F1 -
F12
0 - 255
4,8,2,4,8,..
.
Function mapping for F1 ... F12
-
#47
------
-
#48
------
3.9
#49
HLU acceleration
0 - 255
0
Multiplied by .4 equals acceleration time in seconds
3.9
#50
HLU deceleration
0 - 255
0
Multiplied by .4 equals deceleration time in seconds
3.9
#51
-
55
HLU speed limits
0 - 255
20, 40…
Speed steps for each of the 5 HLU speed limits
3.6
#56
Motor regulation
0 - 255
55
PID regulation: P-value (tens), I value (ones digit)
3.6
#57
Voltage reference
0 - 255
0
Absolute voltage in tenth of a volt: max motor speed,
= 0: relative to track voltage.
3.6
#58
BEMF intensity
0 - 255
255
Intensity of back-EMF control at the lowest speed step.
3.9
#59
HLU delay
0 - 255
5
Tenth of a second delay after receiving new HLU limit
3.18
#60
Dimming
0 - 255
0
Reduction of function output voltage with PWM
3.14
#61
ZIMO ext. mapping
1,2...97,98
0
Configurations not covered by NMRA mapping
3.21
#62
Effects modifications
0 - 9
0
Change of minimum dimming value
3.21
#63
Effects modifications
0 - 99
51
Tens digit: cycle time, Ones digit: extends OFF time
3.21
#64
Effects modifications
0 - 9
5
Ditch light off-time modification
3.3
#65
Sub-Vers Number
Read only
-
Supplement to main version noted in CV #7.
