32
When the tiller reaches it’s lowest point your will
hear a positive click. The tiller is now locked.
RAISING THE TILLER
In order to raise the tiller you must lift up on the tiller
adjustment lever. Continue to hold the tiller
adjustment lever up until the tiller reaches the
position you desire. Then release lever to lock.
SEAT ROTATION
The seat lock lever locks the seat in one of four
positions.
1. Pull up on the seat lock lever to unlock the
seat.
2. Rotate the seat to the desired position.
3. Release the seat lock lever to lock the seat
securely in place.
FRONT-TO-BACK SEAT ADJUSTMENT
You can reposition the scooter’s seat forward or
rearward to one of three settings thereby adjusting
the distance between the seat and the tiller. (Figure
11).
1. Remove the seat from your scooter
2. Remove the four bolts that fasten the seat to
the seat platform. (Figure 11).
3. Align the seat platform with the desired set of
holes on the seat.
4. Replace and tighten the four bolts securely.
ARMREST WIDTH ADJUSTMENT
The scooter armrest width can be adjusted inward
or outward.
1. Loosen the armrest adjustment knobs at the
back of the seat frame. (Figure 11).
2. Slide the armrests in or out the desired width.
3. Tighten the armrest adjustment knobs as
required.
The armrests can also be lifted upward to aid in
getting onto and off of your scooter.
Armrest Adjustment
Knobs
Bolts Seat Lock
Lever
FIGURE 11.
SEAT
ADJUSTMENTS
COMFORT ADJUSTMENTS
