10Front Hub Bearing Removal
Insert the 17 mm Bearing Puller slotted attachment through the non-
drive side bearing. Align the slotted attachment with the bottom of the
bearing, and expand it inside the bearing.
Do not over tighten the slotted attachment. For more detailed
assembly and usage, see the bearing puller manufacturer's
instructions.
Grip the slide hammer and forcefully pull away from the slotted
attachment to remove the bearing from the hub shell.
NOTICE
To prevent damage when pressing the bearing into the hub, make
sure that the bearing press tools contact both the inner and outer
bearing races, and not the hub shell.
Clean the hub shell with isopropyl alcohol and a shop towel.
6
17 mm Slotted Attachment
7
Isopropyl alcohol Shop towel
To Next Page
