Zipro Dream - Parts List

29
EN
PARTS LIST
No.
Description
Quantity No.
Description
Quantity
1 Lower frame 1 63 Main frame hole plug 2
2 Main frame 1 64 Hexagonal bolt M10x55 1
3 Treadmill column 2 65 Hexagonal bolt M10x50 2
4 Upper frame 1 66 Hexagonal bolt M10x40 1
5 Inclination frame 1 67 Hexagonal bolt M10x15 18
6 Reinforcing bar 1 68 Hexagonal bolt M8x50 2
7 Handling wheel bracket 2 69 Hexagonal bolt M8x45 1
8 Rail bracket 2 70 Hexagonal bolt M8x40 5
9 Front roller 1 71 Hexagonal bolt M8x15 2
10 Rear roller 1 72 Hexagonal bolt M8x55 1
11
Cylinder
1
73
Hexagonal bolt M8x35
1
12L/R Metal speaker grille, left/right 1/1 74 Nut M8x18 4
13
Handling wheel brake
2
75
Nut M6x45
1
14 Damper spring 6 76 Nut M6x55 2
15
D axis
2
77
Nut M6x12
2
16 Handling wheel axle 2 78 Countersunk bolt M6x30 6
17 Separator 2 79 Countersunk bolt M6x25 2
18 Bump 8 80 Cross ST2.2x8 4
19 Computer display 1 81 Cross M4x8 4
20 Lower computer display lid 1 82 Cross M5x16 17
21 Upper frame upper cover 1 83 Cross M4x15 2
22 Upper frame lower cover 1 84 Cross M5x8 5
23L/R Speaker cover, left/right 1/1 85 Bolt M5x25 8
24 Bottle holder 2 86 Bolt M3x18 2
25 Computer panel upper cover 1 87 Cross-head bolt ST4x16 52
26
Lower computer panel lid
1
88
Cross
-
head bolt ST4x12
10
27 Handle upper cover 1 89 Bolt ST4.0x12 12
28
Lower handle cover
1
90
Cross
-
head bolt ST2.9x9.5
14
29 Safety key hole 1 91 Lock washer φ10x1.2 22
30
Safety key
1
92
Lock
washer Φ8x1.2
8
31a/b Heart rate sensor, left 1/1 93 Lock washer φ6x1.2 3
32a/b
Heart rate sensor, right
1/1
94
Flat washer φ13xφ8x1.2
10
33L/R Handle side cover, left/right 1/1 95 Spring washer φ8 6
34 Column side external cover 2 96 Nylon nut M10 4
35 Column side internal cover 2 97 Nylon nut M8 10
36L/R
Column lower protective cover,
left/right
1/1 98 Nylon nut M6 2
37
Motor cover
1
99
Nut M3
2
38 Motor cover masking frame, left a 1 100 Nut φ8 4
39
Motor cover masking frame, left b
1
101L/R
Front roller cover, left/right
1/1
