Zipro Notus - Parts List

28
EN
PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 40 Speed control button
SPEED + / -
1
2 Lower frame 1 41 Signal cable 1
3 Treadmill column 2 42 Computer 1
4 Upper frame 1 43 Computer cable 1
5 Inclination frame 1 44 Safety key 1
6 Motor frame 1 45 Sensor 1
7 Front roller 1 46 Computer decal 1
8 Rear roller 2 47 Wrench 17*13*14* Φ5*70 1
9 Cylinder 1 48 Allen wrench 6# 80*80 mm 1
10 Running board t15*520*1130 1 49 Cable 5
11
Running belt t1.4*400*2520
1 50 Sticky battens 4
12 IGBT 200-J5 1 51 Bolt M8*85 1
13 Computer 1 52 Screw M8*60 2
14 Upper motor cover 1 53 Screw M8*12 2
15 Lower motor cover 1 54 Bolt M8*85 1
16 Rear left frame end cap 1 55 Bolt M8*15 4
17 Rear right frame end cap 1 56 Bolt M8*30 3
18 Side left frame end cap 1 57 Bolt M8*40 2
19 Side right frame end cap 1 58 Bolt M8*45 3
20 Main frame edge 2 59 Bolt M8*50 2
21 Handling wheel 4 60 Bolt M8*60 4
22 Wheel washer 2 61 Bolt Φ10*15*(M8*10)S17 4
23 Rubber damper washers 2 62 Screw M10*45 1
24 Damper 8 63 Screw M10*60 5
25 Rubber washers 4 64 Bolt M6*40 8
26 Rubber damper washers 2 65 Bolt M4*8 2
27 Foam grips 2 66 Bolt M5*10 4
28 Power cord clamp 6W3-4 1 67 Bolt ST4*45 2
29 Electrical connector 1 68 Bolt ST4*30 6
30 Fuse 1 69 Bolt ST4*40 4
31 Power cord 1 70 Bolt ST4*15 16
32 Two-conductor cable 1 71 Nut M8 14
33 Single conductor cable 2 72 Nut M10 6
34 Ground 1 73 Washer Φ9* Φ16*t1.5 16
35 Inclination motor 1 74 Washer Φ11* Φ20*t1.5 6
36 Motor 1 75 Spring washer Φ8.1* Φ12.3*t2.1 2
37 Magnetic ring 1 76 Spring washer Φ10.1* Φ14.3*t2.5 4
38 Belt angle adjustment mechanism 1 77 Railing end cap 2
39 Inclination control button
INCLINE + / -
1
