NG5-NG7-NG9
D01474-16 3
657
565
220
226
267
619
Ø6.5
Ø6.5
657
Mechanical dimension with Air Pump
N.B. All dimensions are expressed in mm.
Drilling details with Air Pump
UP
Advised Installation
N.B. All dimensions are expressed in mm
