Zline KB-36 User Manual

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
BUTTON/CONTROL PANEL OPERATION 3
WALL RANGE HOOD INSTALLATION 4
CROWN MOLDING INSTALLATION 9
DESIGNER WALL RANGE HOOD INSTALLATION 10
ISLAND RANGE HOOD INSTALLATION 15
DESIGNER ISLAND RANGE HOOD INSTALLATION 19
UNDER CABINET INSTALLATION 23
RANGE HOOD INSERT INSTALLATION 27
REMOTE BLOWER INSTALLATION 29
HOW TO CHANGE PARTS 31
TROUBLESHOOTING AND FAQ 42
MOUNTING SPECIFICATIONS 48
Proper Venting Regulations
Please verify with your local, city, and state regulations on the proper venting method for
your hood. Many agencies have CFM rating specifications for your hood, as well. You
may have to purchase additional items on your own to vent the hood in accordance with
your local city and state specifications. Our ZLINE dual motor range hoods come with
an 8” metal transition piece without a backdraft damper and a piece of 4’ metal ducting.
Our ZLINE single motor units come with a plastic 6” plastic transition piece with a back-
draft damper and a 4’ long piece of flexible ducting.

Zline KB-36 Specifications

General

Color	stainless steel, brushed stainless steel
Hood Type	wall
Venting Type	convertible, external
Number of Fan Speeds	4
CFM	400 cubic feet per minute
Control Type	button
Interior Light	yes

Weight and Dimensions

Depth	19 7/10 inches
Height	10 1/2 inches
Width	36 inches
Net Weight	42 pounds
