STEP 13: CONNECTING THE WATER SUPPLY LINE
1. Make sure that you wrapped the 90° elbow with Teflon thread seal tape twice.
2. Slide the compression nut, then the ferrule over the end of the water supply line.
Note: If you use braided stainless steel, you do not need a ferrule or
compression nut.
3. Insert the water supply line into the 90° elbow.
4. Slide the ferrule against the 90° elbow and secure it with the compression nut.
Important: Make sure that the door spring does not rub or contact the
water supply line or drain hose. Test by opening and closing the door.
Reroute the lines if interference occurs.
YOU’LL NEED
• Adjustable wrench
• Hot water line kit
• Teflon thread seal tape
INSTALLATION
28
Connecting the Water Supply Line
