¢TECHNICAL SPECIFICATIONS
General
Maximum number of channels: 255
Frequency range:
66-88 MHz
136-174 MHz
405-470 MHz
Channel separation: 12,5 kHz / 25 kHz
Battery type: Lithium-Ion
Battery capacity: 1800 mAh
Operating time (5:5:90): ca 16 timer
Stand by-time: ca 45 timer
Temperature range:
-30◦C - +60◦C
Frequency stability: +- 2.5ppm
Size (wxhxd): 56x100x34 mm
Weight w / battery: 285g
Pilottones: 39 st
Receiver
Sensitivity 12 dB Sinad: 0,20 uV
Adj. channel rejection: 70dB (25 kHz)
Intermodulation: 65 dB
Spurious and mirror att.: 70 dB
Audio output power @ 5%
dist.:
700 mW @ 16Ohm
Transmitter
Output power: 5 W / 2.5 W / 1 W
Modulation: FM 16K0F3
Spurious (conducted): 70 dB
Signal / Noise ratio: 45 dB (25 kHz)
LF distortion @ 1 kHz: <5 %
