ZOJE B9500 - Page 27

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10009643 左盖 left cover 1
2 10007842 螺钉 screw 1
3 10009195
螺钉
screw
5
4 10009104 螺钉 screw 1
5 10009519 左盖 left cover 1
6 10010595 螺钉 screw 3
7 10009448 O型圈 O ring 1
8 10025895 6202N2-RZ_BOM轴承 bearing 1
9 10009334 O型圈 O ring 2
10 10012162 螺钉 screw 1
11 10002966 轴承套 bush mounted in bearing 1
12 10009167 螺钉 screw 1
13 10009187 螺钉 screw 1
14 10009479 主轴轴芯 the spindle axis core 1
15 10058553 主轴(普通料机械) main shaft(general machine) 1
10058550 主轴(厚料机械) main shaft(heavy machine） 1
16 10009402 平衡块 balance block 1
17 10003001 螺钉 screw 4
18 10008898 主轴卡圈 main shaft retainer ring 1
19 10009780 6203轴承 bearing 1
20 10009392 蜗杆套 bush mounted in worm bush 1
21 10009362 蜗杆 wrom bush 1
22 10055917 螺纹套 bush mounted in screw 1
23 10009360 O型圈 O ring 1
24 10055926 6303V轴承BOM
bearing
1
25 10055918 右盖垫片 spring washer 1
26 10055919 O型圈 O ring 1
27 10055920
右盖
right cover 1
28 10059605
风扇
fan 1
29 10059606
电机组件
motor 1
30 10005537
垫圈
washer 4
31 10001497 螺钉 screw 4
32 10058555 手轮组件 hand wheel assembly 1
33 10003151
螺钉
screw 4
34 10003249
垫圈
washer 1
35 10001901
螺钉
screw 1
5.主轴机构/MAIN SHAFT MECHANISM
