ZOJE B9500 - Page 31

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10009576 橡胶塞 rubber plug 1
2 10009245 螺钉 screw 1
3 10009374
直针曲柄
crank on needle bar 1
4 10009345 直针曲柄销 crank pin for needle bar 1
5 10008090 油线 oil wick 1
6 10009423 针杆传动轴 driving shaft for needle bar 1
7 10009433 针杆传动曲柄 crank on needle bar drive shaft 1
8 10009164 螺钉 screw 1
9 10009357 挡圈 rataining ring 1
10 10009074 螺钉 screw 2
11 10033718 垫圈 washer 1
12 10003273 挡圈 rataining ring 1
13 10009109 螺钉 screw 1
14 10009432 直针连杆销 pin for connecting rod 1
15 10002961 直针传动连杆 connecting rod for needle bar 1
16 10002939 螺钉 screw 2
17 10009386 针杆 needle bar 1
18 20001229 针夹头夹组件 the needle clamp clip 1
19 10009344 针夹头夹 the needle clamp clip 1
20 10010888 螺钉 screw 1
21 10009400 夹线簧 spring 1
22 10009341 下夹线板 lower thread tension plate 1
23 10009386 上夹线板 upper thread tension plate 1
24 10009383 螺钉 screw 1
25 10009391 O型圈 O ring 1
26 10009401 针杆套 needle bar bush 1
27 10009356 针杆套毛毡 felt 1
28 * 针夹头 needle holder 1
29 10003431
针夹头过线板
thread guide plate of needle holder
1
30 10009422
螺钉 screw
1
31 10009255
螺钉 screw
*
32 10009339
针夹头过线板
thread guide plate of needle holder
1
33 10009644 针夹头过线板
thread guide plate of needle holder
1
34 10009664 螺钉 screw 1
35 10008205
针夹头过线板
thread guide plate of needle holder
1
36 *
机针 needle
1
*:参看专用件表/see the guage list
7.针杆传动机构(1)/NEEDLE DRIVE MECHANISM(1)
