ZOJE B9500 - Page 33

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1*针板 needle plate 1
2 10009290 螺钉 screw 2
3 10009354
针板托
needle plate support 1
4 10010595 螺钉 screw 4
5 10009420 针板座 base of needle guard 1
6 10061231 防震橡胶垫 rubber cushion 2
7 10012905 销 pin 1
8 10009377 直针前护针架（3、4线）
front needle guard(3、4thread machine)
1
10009637 直针前护针架（5、6线）
front needle guard(5、6thread machine)
1
9 10010595 螺钉 screw 1
10 10040242 链弯针前过线板 frent thread guide 1
11 10004171 螺钉 screw 1
12 10009306 护针座 needle guard barcket 1
13 10009636 链弯针后护针 rear needle guard 1
14 10009657 链弯针前护针 front needle guard 1
15 10009638 螺钉 screw 2
16 10010555 螺钉 screw 2
17 10010555 螺钉 screw 2
18 10058562 针板座 base of needle guard 1
19 10010554 螺钉 screw 1
20 10009023 直针后护针 rear needle guard 1
21 10003274 垫圈 washer 1
22 10009021 螺钉 screw 1
23 10009020 螺钉 screw 1
24 10009048 销 pin 1
*:参看专用件表/see the guage list
8.针杆传动机构(2)/NEEDLE DRIVE MECHANISM(2)
