ZOJE B9500 - Page 35

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10039396 橡皮塞 rubber plug 1
2 10039397 挡油架 oil baffle frame 1
3 10009349
螺钉
screw 1
4 10005537 垫圈 washer 1
5 10033711 垫圈 washer 1
6 10009338 挡圈 retaining ring 1
7 10003062 上弯针球曲柄
crank bush with ball head for upper looper
1
8 10009164 螺钉 screw 1
9 10009404 上弯针轴 drive shaft for upper looper 1
10 10009373 上弯针摇杆 swing bar for upper looper shaft 1
11 10009245 螺钉 screw 1
12 10009240 螺钉 screw 1
13 10003064 弯针传动连杆
connecting bar for upper looper drive
1
14 10002939 螺钉 screw 4
15 10009431 连杆挡板 fender for connecting bar 1
16 10009626 螺钉 screw 1
17 10002912 滑杆座 sliding bar bracket 1
18 10009008 螺钉 screw 2
19 10009405 毛毡 felt 1
20 10002905 滑杆套 sliding bar bush 1
21 10009370 盖板 cover plate 1
22 10009379 螺钉 screw 1
23 10013969 螺钉 screw 1
24 * 上弯针 upper looper 1
25 10002913 滑杆 sliding bar 1
26 10009406 销 pin 1
27 10008067 油线 oil wick 1
*:参看专用件表/see the guage list
9.上弯针传动机构/UPPER LOOPER DRIVE MECHANISM
