序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10009349 螺钉 screw 1
2 10005537 5弹簧垫圈 washer 1
3 10033711
垫圈
washer 1
4 10009404 上弯针轴 drive shaft for upper looper 1
5 10003061 下弯针球曲柄 crank bush with ball head for 1
6 10002825 链弯针左曲柄
left crank bush with chain stitch loope
r
1
7 10009164 螺钉 screw 1
8 10009399 油封 seal ring 1
9 10003064 弯针传动连杆
connecting bar for upper looper
1
10 10002939 螺钉 screw 4
11 10009431 连杆挡板 fender for connecting bar 1
12 10009626 螺钉 screw 2
13 10009026 下弯针架 stand for lower looper 1
14 * 下弯针 upper looper 1
15 10000164 螺钉 screw 1
16 10009394 螺钉 screw 1
17 10031107 螺钉 screw 1
18 10059412
下弯针架
stand for lower looper
1
*:参看专用件表/see the guage list
10.下弯针机构/LOWER LOOPER MECHANISM
