序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10009309 链弯针轴 shaft for chain stitch looper 1
2 10009071 密封圈 seal ring 1
3 10009394
螺钉
screw 1
4 10010643 螺钉 screw 2
5 10009310 螺钉 screw 2
6 10009307 链弯针架 stand of chain stitch looper 1
7 10003294 挡片 blocking ring 1
8 10009142 螺钉
screw
2
9 10009192 垫圈 washer 1
10 10023487 连杆销套 needle pin for connecting bar 1
11 10009186 送料连杆 connecting bar of feed dog 1
12 10009245 螺钉 screw 1
13 10009302 摆动曲柄 swing crank 1
14 10009245 螺钉 screw 1
15 10009305 摆动叉 swing fork 1
16 10047854 链弯针传动连杆
connecting bar for chain stitch looper
1
17 10009142 螺钉 screw 1
18 10009192 垫圈 washer 1
19 10023487 连杆销套 needle pin for connecting bar 1
20 10009308 调节曲柄 crank of regulator 1
21 10009311 偏心销 pin 1
22 10009641 0型圈 O ring 1
23 10009303 调节座 base of regulator 1
24 10009192 垫圈 washer 1
25 10005537 垫圈 washer 1
26 10014210 螺钉 screw 1
27 10034624 调节杆轴 shaft of adjusting bar 1
28 *
链弯针 chain stitch looper
1
*:参看专用件表/see the guage list
11.链弯针机构/CHAIN STITCH LOOPER MECHANISM
