ZOJE B9500 - Page 41

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10010693 过线管夹簧 elastic clamp for thread guide 3
2 10009283 横过线管 horizontal thread guide pipe 1
3 10010609
夹线螺母
thread tension nut 1
4 10010612 弹簧 spring 1
5 10010613 夹线板 thread tension dish 2
6 10010610 螺钉 screw 1
7 10010654 过线架 thread guide plate 1
8 10009529 螺钉 screw 1
9 10009529 螺钉 screw 1
10 10010614 过线板 thread guide plate 1
11 10010596 垫圈 washer 1
12 10010611 过线架 thread tension stand 1
13 10010596 垫圈 washer 2
14 10010556 螺钉 screw 1
15 10033740 打线架 thread take-up stand 1
16 10004171 螺钉 screw 1
17 10010664 打线凸轮组件 thread take-up cam assembly 1
18 10010196 螺钉 screw 2
19 10009285 竖过线管 the vertical line pipe 1
20 10009556 螺钉 screw 1
12.打线凸轮部件/CAM ASSEMBLY
