ZOJE B9500 - Page 47

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10037470 上刀轴 shaft of upper knife drive 1
2 10009070 上刀架紧固销
fastening pin for upper knife holder
1
3 10009078
上刀轴挡圈
retaining ring 2
4 10011177 螺钉 screw 2
5 10009434 上刀轴曲柄 crank of upper knife drive 1
6 10009164 螺钉 screw 1
7 10002942 上刀轴传动连杆
connecting bar of upper knife drive
1
8 10009432 直针连杆销 pin for connecting bar 1
9 10009109 螺钉 screw 1
10 10002939 螺钉 screw 2
11 10009068 上刀架 upper knife holder 1
12 10009037 螺钉 screw 1
13 * 上刀 upper knife 1
14 10009483 螺钉 screw 1
15 10009075 螺钉 screw 1
16 10058572 弹簧挡板 fender of spring 1
17 10014399 弹簧 spring 1
18 10009045 下刀架 lower knife holder 1
19 * 下刀 lower knife 1
20 10009043 下刀压板 press plate for lower knife 1
21 10055368 螺钉 screw 1
22 10009656 上刀架 upper knife holder 1
23 10008165 下刀架 lower knife holder 1
24 10009301 下刀架 lower knife holder 1
25 10023652 下刀架 lower knife holder 1
*:参看专用件表/see the guage list
15.切料机构/KNIFE DRIVE ASSEMBLY
