ZOJE B9500 - Page 49

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10058290 调压螺钉
screw for adjuesting pressure of presser foot
1
2 10057465 调压螺母
nut for adjuesting pressure of presser foot
1
3 10057462
O型圈
O ring 1
4 10057460 压脚杆螺纹套 press pin threaded sleeve 1
5 10057464 O型圈 O ring 1
6 10062471 压脚杆塑料套 press pin plastic cover 1
7 10062472 弹簧 spring 1
9 10002844
销 pin
1
塑料垫
plastic mat
1
11 10057463
O型圈 O ring
1
12 10061365 压脚安全开关磁铁 foot safety switch magnet
13 10058563 压脚臂 arm of presser foot lifting
15 10037480 切刀防护板 guard plate of cutter
16 10011912 割线刀 secant knife
17 10009529 螺钉 screw
18 10062481 压脚扳手 hand lifter of presser foot
19 10063382 压脚扳手扭簧 spring
20 10057459 扳手螺钉 screw
21 10009032 压脚轴 shaft of presser foot
22 10061300
压脚轴套 bush of presser foot lifting
23 10023463
螺钉
screw
24 10037485
扭簧
spring
25 10033721
抬压脚连杆
connecting bar for presser foot lifting
26 10009616
螺钉
screw
27 10034616
抬压脚曲柄
crank for presser foot lifting
28 10009622
抬压脚拉杆
pulling lever for presser foot
29 10009158
抬压脚杠杆
lever for the presser foot
30 10009036
杠杆扭簧
torsing spring for lever
31 10036965 螺钉 screw
32 10009623 螺钉 screw
33 10009467 螺母
nut
34 10009159 制动板
brake plate
35 10009104 螺钉 screw
14 * 压脚组件 presser foot components
*:参看专用件表/see the guage list
16.压脚机构/PRESSER FOOT ASSEMBLY
8 10057455 压脚杆 bar of presser foot
10 10009454
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
