Instructions Manual
First Edition: May 2018
II
Explanation of Symbols
The following symbols appear on the monitor and its packaging.
Table 1 Monitor and Packaging Symbols
Symbol
Description
Symbol
Description
CE mark
Caution, consult
accompanying documents
Keep dry
-2 0℃
5 5℃
Temperature limitations
22kPa
107.4kPa
Atmospheric pressure
limitations
10%
93%
Humidity limitations
Keep upright
Fragile, handle with care
Recovery
Maximum stacking
Recyclable
Power On key
Waveform Freeze key
Record key
AC Power LED
NIBP key
CO
2
CO
2
connector
Charging LED
NIBP
NIBP cuff hose connector
ECG/RESP
ECG connector (3/5-lead)
MasimoSET SpO
2
connector
SpO
2
SpO
2
probe connector
TEMP1
TEMP1 connector
Main Menu
TEMP2
TEMP2 connector
IBP1
IBP1 transducer cable
connector
Gas input
IBP2
IBP2 transducer cable
connector
C.O.
C.O. connector
ECG
ECG connector (12 Lead)
USB port
Gas output
BF applied part: including F
applied part (float/insulation)
BF applied part: including F
applied part (float/insulation)
