Form 2045-0803 © Copyright Trolex Corporation & ZoneFirst P a g e | 2
6 Aspen Drive - Randolph, NJ 07869 | 1-877-FirstZone (347-7896)
ZoneFirst.com | Shop Online at ZoneDampers.com | fb.com/ZoneFirst
MASTERZONE
™
ZONING SYSTEM
FEATURES
Zone Terminals for Zone
Damper Motors and Zone
Thermostats
24VAC Transformer
Terminals
Re
-
Settable Fuse
Zone Calling Indicators
Mode DIP Switches
HVAC Equipment
Terminals
r
Terminals
ZONE ADDER
RJ11 Connection
Adjustable Heating Limit
Mounting Keyholes
Two at Top also.
Adjustable Second
Stage Timer
Power Indicator LED
Boot Button
System Mode Indicator LED
Purge Override
Button
No
Sensor
Jumper
