Zonet ZFS3124 - Ethernet Switch; LED Definition

16 / 24-port 10/100 Ethernet Switch
LED Definition:
Please refer to the following table for LED definition
Front Panel
1. 16 Ports 10/100 Internal Power Switch
2. 24 Ports 10/100 Internal Power Switch
LED Status Operation
Power
Green Lit: Power is on
Link/act
Green
Lit: Indicates the adapter is connected
to swich correctly
Flash: the port is transmitting/receiving
data.
10/100
Green
Lit: 100M bps
Not lit: 10M bps
Rear Panel
1-3 LED Definition
