Zoom B1 FOUR User Manual

Using patches (MEMORY mode)
The manages effects in patches. A patch can have up to ve effects and save their ON/
OFF states and parameter settings.
1 2 3 4 5
Patch
IN OUT
Effect
Up to 50 patches can be created. Groups of 10 patches are organized into banks, so effects can be quickly
recalled by switching banks.
Select patches to use in MEMORY mode.
Switching to MEMORY mode
HINT
MEMORY mode is shown when the
starts up.
1.
When using STOMP or EDIT mode, press .
Pressing
repeatedly, cycles through the MEMORY, STOMP and EDIT modes in order.
12

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
