Zoom B1 FOUR User Manual

Terms used in this manual
Patch
A “patch” stores effect ON/OFF states and parameter setting values. Effects are saved and recalled in units
of patches. Five effects can be added to one patch, and the
can store up to 50 patches.
Bank
One group of 10 patches is a “bank”. Patches can be quickly recalled by switching banks. The
has 5 banks.
Effect type
The available effect types include various bass effects and amp/cabinet simulation models. Effects can be
selected from these types to be added to patches.
MEMORY mode
This mode allows you to select patches with the footswitches.
STOMP mode
Use this mode to turn effects in a patch ON/OFF with the footswitches.
EDIT mode
In this mode, edit the types and parameters and effects used in a patch.
PRESELECT
This function allows you to switch to a patch at any location while continuing to use the tone of the cur-
rently selected patch.
BANK HOLD
This function allows patch switching to be limited to the current bank.
AUTO SAVE
This function automatically saves changes to patch and effect settings.
ECO mode
This function will automatically turn the power off 10 hours after the last operation.
3

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
