Zoom B1 FOUR User Manual

B1 FOUR/B1X FOUR structure
Signal ow
AUX IN
INPUT
OUTPUT
1
1 2 3 4 5
Patch
Patch
level
Output
EQ
Output
volume
Tuner
Effect
Looper
Rhythm
The input bass sound passes through effects 1 – 5 in order.
( “Using patches (MEMORY mode)” on page 12)
The patch level is adjusted.
( “Using patches (MEMORY mode)” on page 12)
The overall sound is adjusted. This setting is retained even when the patch is changed.
( “Adjusting the overall audio character and output level” on page 11 )
Recorded phrases can be played back in a loop.
( “Using the looper” on page 47)
Drum sounds can be played back using built-in rhythm patterns.
( “Using rhythms” on page 43)
The overall level is adjusted.
( “Adjusting the overall audio character and output level” on page 11 )
This function enables tuning the connected bass.
( “Using the tuner” on page 39)
5

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
