Zoom U-22 - Right side; Front

XLR TRS
1：GND
2：HOT
3：COLD
TIP：HOT
RING：COLD
SLEEVE：GND
1
2
3
4 5
Part Names
LINE IN jack PHONES jack
MIC/Hi-Z jack
POWER SOURCE switch
48V switch
DIRECT MONITOR switch
Front
Right side
Part Names (continued)
