A
B
C D
E
INTERIOR SHELF X 2PCS
BACK BOTTOM STRETCHER X 1PC
FRONT TOP STRETCHER X 1PC
SIDE PANEL 1 X 1PC
PARTS LIST
SIDE PANEL 2 X 1PC
1
PTF0071720110/PTF0081721710 - WINDSOR PET FEEDER
NOTE: Please read all instructions carefully before starting a
Also, we recommend that the unit is fully assembled on a level
Two people are recommended to assemble this product.
DO NOT over torque screws and bolts.
F
BACK PANEL X 2PCS
G
TOP PANEL X 1PC
H
DRAWER SIDE X 2PCS
UP
