ZORKI-10 User manual, 1965 year
– 3 –
Fig. 4
18. Film pressure
plate
19. Take-up
spool
20. Film advance
sprocket
21. Rewind
spool spindle
4. Loading the Camera
When loading the camera avoid direct sunlight. Always load and unload film in subdued light or
shade. Place the camera on some soft material to prevent any damage when loading the camera and
load in the following order:
Fig. 5
1
.
Pull
up the back cover lock and open the back cover
(Fig. 5).
Fig. 6
2
.
Turn the film rewind head 12 (Fig. 3) clockwis
e, pull
until it stops and remove cassette out of the camera (Fig.
6). Place the loaded cassette into the camera and bring the
film rewind crank to its original position.
Fig. 7
3
.
Turn the cocking shutter lever until the take-
up spool
slot appears at top. Insert the exposed film strip tip firmly
into the take-up spool slot (Fig. 7).
