Zotac MEK ULTRA

3
EN
REAR PANEL
1. USB 3.0 ports
2. PS2 keyboard/mouse port
3. USB 3.1 Type-C ports
4. USB 3.1 port
5. LAN port
6. WiFi antenna connectors
7. Audio ports with SPDIF-out
8. DisplayPorts
9. HDMI port
10. Power input
11. Power switch
INSTALLING THE GLASS SIDE COVER
1. Rotate and remove the two screws securing the iron side cover.
2. Gently push the iron side cover and remove it as shown below.
3. Insert the glass side cover to the side of the MEK ULTRA PC Gaming system,
and ensure that the installation is in place.
4. Use a coin to turn the screw to secure the glass side cover.
1
2
3
4


10 11
1
2
3
4
6
7
9
8
1
5
8
8
3
