ZUCCHETTI AZZURRO ZCS User Manual (English)

Questions and Answers:

J
Joseph ColemanAug 17, 2025
What to do if my ZUCCHETTI AZZURRO ZCS Battery Charger shows a ground fault?
- K
  Kimberly HarmonAug 17, 2025
  If the ZUCCHETTI Battery Charger displays 'Ground fault', immediately switch off the circuit breaker for the leakage current of the power distribution. Then, check if the input/output cables are in normal condition, and if the L/N input connection cables have been reversed. The ground connection of the input/output cables or the reverse connection of the L/N input cables may be incorrect.
J
jwestAug 20, 2025
What to do if my ZUCCHETTI AZZURRO ZCS Battery Charger has leakage overcurrent?
- S
  Seth CollinsAug 20, 2025
  If the ZUCCHETTI Battery Charger indicates 'Leakage overcurrent', immediately switch off the circuit breaker for the leakage current of the power distribution. Also, check for damaged AC output cables or a low resistance ground connection. This issue arises when the current discharged to the ground is excessively high.
D
daniel91Aug 23, 2025
What to do if my ZUCCHETTI AZZURRO ZCS is showing input overcurrent?
- M
  Madeline ReedAug 23, 2025
  If the ZUCCHETTI Battery Charger displays 'Input overcurrent', check whether there is a low resistance connection between the AC outputs of the charger cable. Immediately switch off the circuit breaker for the leakage current of the power distribution. This can happen if the input current on the AC side is too high.
M
Michael WhiteAug 26, 2025
What to do if my ZUCCHETTI AZZURRO ZCS is showing input overvoltage?
- W
  William HallAug 26, 2025
  If the ZUCCHETTI Battery Charger displays 'Input overvoltage', first check the input voltage from the back-end. If the voltage is higher than 264Vac for a limited period of time, wait for the grid to re-establish an adequate voltage value. This issue occurs when the input voltage on the AC side is too high.
S
Sara ScottAug 28, 2025
What to do if my ZUCCHETTI Battery Charger is showing input undervoltage?
- L
  Lindsay YoungAug 28, 2025
  If the ZUCCHETTI Battery Charger displays 'Input undervoltage', check the input voltage from the back-end. If the voltage is below 140Vac for a limited period of time, wait for the grid to re-establish an adequate voltage value. This issue occurs when the input voltage on the AC side is too low.
A
Amber OchoaAug 31, 2025
What to do if my ZUCCHETTI AZZURRO ZCS displays abnormal current leakage sensor?
- R
  Ricardo BakerAug 31, 2025
  If the ZUCCHETTI Battery Charger displays 'Abnormal current leakage sensor', immediately switch off the circuit breaker for the leakage current of the power distribution. Also, check for damaged AC output cables or a low resistance ground connection. This problem appears if the value measured by the leakage current sensor is abnormal.
J
jasonmillerSep 2, 2025
What to do if my ZUCCHETTI AZZURRO ZCS is showing input overfrequency?
- T
  Tammy StricklandSep 3, 2025
  If the ZUCCHETTI Battery Charger displays 'Input overfrequency', check the input voltage frequency from the back-end. If the frequency is higher than 55Hz for a limited period of time, wait for the grid to re-establish an adequate value. This issue occurs when the input frequency on the AC side is too high.
M
mooreangelaSep 5, 2025
What to do if my ZUCCHETTI AZZURRO ZCS Battery Charger is showing input underfrequency?
- N
  Nicole BruceSep 5, 2025
  If the ZUCCHETTI Battery Charger displays 'Input underfrequency', check the input voltage frequency from the back-end. If the frequency is below 45Hz for a limited period of time, wait for the grid to re-establish an adequate value. This issue occurs when the input frequency on the AC side is too low.
C
Courtney ParkerSep 8, 2025
Why is my ZUCCHETTI AZZURRO ZCS Battery Charger displaying 'Temperature too high'?
- M
  Megan MarshallSep 8, 2025
  If your ZUCCHETTI Battery Charger indicates that the 'Temperature is too high', verify the ambient conditions around the charger. Ensure there is no nearby heat source and confirm that the temperature remains below 60°C. This issue arises when the temperature inside the charger becomes excessively high.
M
Michael MorrowSep 12, 2025
What causes an abnormal CAN-side communication error on my ZUCCHETTI Battery Charger?
- L
  Lori LewisSep 12, 2025
  If the ZUCCHETTI Battery Charger displays 'Abnormal CAN-side communication', check whether the CAN bus connection is reliable and correct. The connection between the AC charger and the ENGATE may be weak.
