2Services Tap
Unscrew the top part of the tap by turning
the matte ring, and follow the cleaning
steps indicated above.
Rinse with water, apply the disinfectant,
rinse again and to finish, dry both the
outside and the inside of the tap with paper
(roll the paper on the pin to aid insertion of
the paper into the holes).
Dose the degreaser by inserting the spray
nozzle into the three orifices and applying
the product. Scrub the inside through
the holes with the aid of the small brush
supplied.
1 32
Zumex Group S.A. Tel. +34 961 301 251. zumex@zumex.com. Zumex Service Tel: +34 960 800 999. www.zumex.com Zumex Group S.A. Tel. +34 961 301 251. zumex@zumex.com. Zumex Service Tel: +34 960 800 999. www.zumex.com
Disassembly instructions
Take off the feeder basket.
Remove the stainless-steel peel guides.
Turn the knobs and take off the front cover
as well as the side outputs.
Remove the 1Step Kit by pulling it towards
you with the stainless-steel handles.
Remove the waste trolleys from the base
to empty them.
Take off the feeder plate by unscrewing the
central knob.
Press the side tabs to remove the bin.
Take off the automatic PulpOut System, by
lifting the assembly with the part closest to
you.
Remove the blade by pressing on the centre
and pulling the handle towards you.
Caution! Put the protector on the cutting zone.
Clean the inside of the podium, following
the steps shown and removing all the par-
ticles which have adhered.
Insert the cleaning brush into the Drain&Clean
hole in the base of the feeder, removing any
residue that you may find in the tube.
Unscrew the central knob of the 1Step Kit.
Remove the 2Services tap by easily un-
screwing it.
Clean the front zone of the machine, fo-
llowing the steps shown and removing all
the particles which have adhered.
Once you have dismounted all the parts,
proceed to the deep cleaning, following the
steps described..
The cleaning process will be explained in details for each one of the machine’s components below.
Caution! For a correct cleaning process, please follow the instructions
below. Before getting started, make sure that the machine is nplugged
from mains power.
Instructions for cleaning the components
All the parts, with the exception of the cover and the tap,
can be put in a dishwasher to clean them.
The juicing zone and its removable components must be
cleaned using Citric Active*. Leave to act for one minute
and then proceed to remove the remains of dirt with a
moist sponge.
Do not use scourers which may scratch the surfaces.
Sanitise with a hydroalcoholic disinfectant** after the
first rinse, and leave it to rest for 1 minute.
Rinse with plenty of water after sterilising, in order to
remove any remaining disinfectant.
Dry the parts completely.
Warnings and steps for cleaning and sanitation
It is necessary to clean all parts that come into contact with the juice each day.
!
Blade, sub-filter, bin, peel guides, feed plate, front cover, and tap
Daily cleaning
Follow the cleaning process indicated, for all
the parts: blade, sub-filter, tank, peel chu-
tes, etc.
Clean the cover, following the steps shown
and removing all the particles which have
adhered.
Unscrew the top part of the tap by turning
the matte ring, and follow the cleaning
steps indicated above.
Wash the feeder plate with Citric Active
and a soft sponge, removing all the parti-
cles which have stuck to it.
* Detergent for food use specific to Zumex Juicers.
** Disinfectant for food use recommended.
!
1
7
4
10
13
2
8
5
11
14
3
9
6
12
15
