Proceptor Grease Separator Sizing Chart
Flow Rating
Model Number
Non-Emulsified Grease
(US gpm)
Emulsified Grease from Sinks Only
(1)
(US gpm)
GMC 50 10 2
GMC 100 20 3
GMC 150 30 5
GMC 200 / GMC250 40 / 50 7 / 8.5
GMC 300 60 10
GMC 500 100 17
GMC 750 150 25
GMC 1000 & GMC 1000(2) 200 33
GMC 1300 260 43
GMC 1500 & GMC 1500(2) 300 50
GMC 2000(2) 400 67
GMC 2600(2) 520 87
GMC 3000(2) 600 100
GMC 4000(2) 800 133
GMC 5000(2) 1,000 167
GMC 6000(2) 1.200 200
GMC 7000(2) 1,400 233
GMC 8000(3) 1,600 267
GMC 9000(3) 1,800 300
GMC 10000(3) 2,000 333
3.3.2 MANUFACTURER GREASE SEPARATOR SIZING CHART
Pipe sizes shown in standard drawings reflect the lowest flow scenario in all cases. Larger pipe sizes are available. It is the
responsibility of the designer to inform Zurn Green Turtle of the design flow rate and pipe size for each project.
Caution: For larger units, or applications involving degreasers, surfactants, emulsifiers, corrosive wastewater, pumped euent
(not gravity fed), contact a Zurn Green Turtle representative.
Notes: (1) Based on 30 minute retention time (ref: Metcalf & Eddy, Inc., Revised by George Tchobanoglous and Franklin L
Burton, Wastewater Engineering: Treatment, Disposal and Reuse. 3rd Ed. , 1991).
3.3.3 PROCEPTOR PDI AND CSA SIZING –
FOR PROCEPTOR GMC-100, GMC-150, GMC-200, GMC-250, GMC-300
as published in PDI- G101 standard – revised March 2010
Sizing Method Based on Pipe Size and Slope
When the final configuration of fixtures in a facility is not known or to allow for additional fixtures in the future, thhis method
shall be used or to size the interceptor for the maximum flow that the drain line from the facility can carry.
Sizing Method Based on Pipe Size and Slope
Pipe Size
(inches)
Full Pipe Flow
@ 1/4 slope
Interceptor Size
1 minute drain
Interceptor Size
2 minute drain
2" 19.44 gpm 20 gpm 10 gpm
3" 58.67 gpm 75 gpm 35 gpm
4" 125.77 gpm – 75 gpm
