PROCEPTOR®
TECHNICAL MANUAL
1 PROCEPTOR OVERVIEW 3
1.1 THE PROCEPTOR SEPARATOR ADVANTAGE 4
1.2 APPLICATIONS 4
1.3 WARRANTY INFORMATION 4
1.4 CONTACT ZURN 5
2 DESIGN AND OPERATION 6
2.1 COMPONENTS & CONFIGURATIONS 6
2.2 PRINCIPLES OF OPERATION 6
3 SIZING GUIDELINES 7
3.1 STANDARD SIZING CONSIDERATIONS 7
3.2 OTHER DESIGN CONSIDERATIONS 8
3.3 GREASE SEPARATORS 8
3.4 OIL SEPARATORS 15
4 ACCESSORIES AND OPTIONS 19
4.1 ALARM 19
4.2 COALESCING FILTER
for Small Diameter Oil Globules (>20 μm) 19
4.3 SUCTION PIPE FOR INDOOR INSTALLATIONS 19
4.4 DOUBLE WALL 19
4.5 LEVEL MONITOR FOR DOUBLE WALL OR OIL RESERVOIR 20
4.6 AUTOMATIC PUMP-OUT SYSTEM 20
4.7 SHUTOFF VALVE SYSTEM WITH ALARM 20
4.8 FIBERGLASS PRODUCTS 20
5 INSTALLATION AND MAINTENANCE 20
5.1 INSTALLATION 20
5.2 MAINTENANCE 20
5.3 IMPORTANCE OF MAINTENANCE 21
5.4 MAINTENANCE FREQUENCY 21
5.5 INSPECTION PROCEDURES 22
5.6 MAINTENANCE METHODS 22
5.7 SPILLS 22
5.8 DISPOSAL 22
6 SPECIFICATION SHEETS 23
7 INSTALLATION 29
8 DRAWINGS: GREASE SEPARATORS 34
9 DRAWINGS: OIL SEPARATORS 34
10 DRAWINGS: SOLIDS SEPARATORS 34
11 DRAWINGS: DECONTAMINATION & HOLDING TANKS 35
