PROCEPTOR®
TECHNICAL MANUAL
BACK TO TOC
3.4.2 OIL SEPARATOR SIZING CHART
Pipe sizes shown in standard drawings reflect the lowest flow scenario in all cases. Larger pipe sizes are available. It is the
responsibility of the designer to inform Zurn Green Turtle of the design flow rate and pipe size for each project.
Caution: For larger units, or applications involving degreasers, surfactants, emulsifiers, corrosive wastewater, pumped euent
(not gravity fed), contact a Zurn Green Turtle representative.
3.4.3 STANDARD OIL SEPARATOR CAPACITY AND DIMENSIONS
Proceptor Oil Separator Sizing Chart
Flow Rating
Model Number
Non-Emulsified Oil without Coalescer
(US gpm)
Non-Emulsified Oil with Coalescer
(US gpm)
OMC 50 2 5
OMC 100 3 10
OMC 150 5 15
OMC 200 7 20
OMC 300 10 30
OMC 500 17 50
OMC 750 25 75
OMC 1000 & OMC 1000(2) 33 100
OMC 1300 43 130
OMC 1500 & OMC 1500(2) 50 150
OMC 2000(2) 67 200
OMC 2600(2) 87 260
OMC 3000(2) 100 300
OMC 4000(2) 133 400
OMC 5000(2) 167 500
OMC 6000(2) 200 600
OMC 7000(2) 233 700
OMC 8000(3) 267 800
OMC 9000(3) 300 900
OMC 10000(3) 333 1000
Standard Oil Separator with Single Accessway
System
Type
Model
Number
Total
Liquid
Capacity
(US gal)
Storage Capacity Tank Dimension
L x W x H
(inches)
Inlet to Tank
Bottom, D1
(inches)
Outlet to Tank
Bottom, D2
(inches)
Oil
(US gal)
Sediment
(US gal)
System 1:
Single Tank
OMC 50 50 12 11 62 x 32 x 24 12 11
OMC 100 100 42 23 62 x 32 x 32 20 19
OMC 150 150 66 48 62 x 32 x 40 28 27
OMC 200 200 90 72 62 x 32 x 48 36 35
OMC 300 300 156 103 62 x 32 x 64 52 51
OMC 500 500 279 87 96 x 62 x 47 32 30
OMC 750 750 410 200 96 x 62 x 60 45 43
OMC 1000 1,000 577 295 96 x 62 x 74 59 57
OMC 1300 1,300 707 446 96 x 62 x 89 74 72
OMC 1500 1,500 819 540 96 x 62 x 100 85 83
