28
PROCEPTOR®
TECHNICAL MANUAL
BACK TO TOC
Specifications (Standard)
Power Input: 110 -240 VAC, 50/60 Hz, 0.15A or 24 VDC, 0.25A
Relay: 2 x SPDT, 10 amp @ 250 VAC, Dry Contact (relays trigger at same setpoint)
Sensitivity: 0.0018 pf
Accuracy: +/- 2 mm
Time Delay: Field Selectable 0 to 600 seconds
Relay: High or Low Selectable
Temperature: Controller Electronics: -4°F to 140°F (-20°C to 60°C)
PMC Electronics: -75°F to 140°F (-60°C to 60°C)
Probe: -75°F to 480°F (-60°C to 250°C)
Wetted Parts: 316SS and Teflon
Process Connection: 3/4" NPT standard
Pressure Rating: max 1500 psi
Housing: Controller: NEMA 4 Metal
PMC Electronics: Epoxy Coated Cast Aluminum
Electrical Rating: Controller: CSA 22.2; UL61010-1
Probe: Explosion Proof Class 1, Div. 1, Group C & D (File # 56812)
