Zycoo X10 - Preface; Target Audience; Revision History

ETH0(PoE 802.3at)
SPEAKER
NO COM NC
+
-
LED2 KEY2
-
+ +
-
LED1
+
-
KEY1
R+ R- L+L-
-
+
RELAY DIN
3.5mm jack for audio in
3.5mm jack for audio out
Speaker Left+
Speaker Left-
Speaker Right-
Speaker Right+
Button 1 Switch+
Button 1 Switch-
Button 1 LED-
Button 1 LED+
Button 2 Switch+
Button 2 Switch-
Button 2 LED-
Button 2 LED+
Digital Level Input-
Digital Level Input+
Dry Contact Signal Normally-Closed Output
Dry Contact Signal Common Input
Dry Contact Signal Normally-Open Output
ETH0+POE
ETH1
SYS
PWR
DC 12V
VOL-VOL+RST
Power Cord
Reset Button
Vol+
Vol-
Power LED Indicator
System LED Indicator
ETH1
Grounding Terminal
Interfaces
2
