No Parameter Name Setting Options Description
00 Quit [00] ESC Exit settings menu
01 Work first mode [01] UTI Default
SOL: PV priority mode, switching to the Mains when
the PV fails or the battery is lower than the set value of
parameter [04].
UTI: Mains priority mode, switching to inverter only
when the mains fail.
SBU: Inverter priority mode, switching to the mains
only when the battery is under voltage or lower than
the set value of parameter [04].
02 Output frequency [02] 50.0Hz/60.0Hz 230V 50Hz or 120V 60Hz mode
03
AC input voltage
range
[03] UPS Default
Operating mode from the mains 170~280 V = UPS
mode; 90~280 V = APL mode.
04
Conversion to
mains electricity
[04] 46.0V Default
When parameter [01] =SOL/SBU and the battery
voltage is lower than the set value, the output switches
from Inverter to mains. Settings range 44V~52V
05 City battery [05] 56.0V Default
When parameter [01] =SOL/SBU and the battery
voltage is higher than the set value, the output is
switched from mains to inverter. Settings range
48V~60V
06 Charging mode [06] SNU Default
CSO: PV priority charging; only when the PV charging
fails, the mains charging is started.
CUB: Mains priority charging; only when the mains
charging fails, the PV charging is started.
SNU: PV and Mains hybrid charging; PV charging is
a priority, and when the PV energy is insufficient, the
Mains charging supplements. When the PV energy is
sufficient, the Mains charging stops.
OSO: Only PV charging, with the Mains charging not
activated.
07
Maximum
charging current
[07] 60A Default Settings range: O~80A
