08 Battery type [08] L16
USE: User-defined battery: all battery parameters can
be set.
SLd: Sealed lead-acid battery: constant-voltage
charge voltage: 57.6V, floating charge voltage: 55.2V.
FLd: Vented lead-acid battery: constant-voltage
charge voltage: 58.4V, floating charge voltage: 55.2V.
GEL: Colloidal lead-acid battery: constant-voltage
charge voltage: 56.8V, floating charge voltage: 55.2V.
LF14/LF15/LF16: F16 default) Lithium iron phosphate
battery: LF14/LF15/LF16, corresponding to 14
strings,15 strings and 16 strings of lithium iron phosphate
battery; for 16 strings, default constant-voltage charge
voltage is 56.8V; for 15 strings, default constant-voltage
charge voltage is 53.2V; for 14 strings, default constant-
voltage charge voltage is 49.2V; allow adjustable.
09
Increase charging
voltage
[09] 57.6V Default
Charging voltage. The setting range is 48V~58,4V,
the step is 0.4V. Valid only when the battery type is
custom and it is a lithium battery
10
Increase the
maximum
charging time
[10] 120 Default
Maximum charging time with constant voltage [09].
The setting range is 5min~900min with a step of 5
minutes. Valid only when the battery type is custom
and it is a lithium battery
11 Float voltage [11] 55.2V Default
Float charge voltage. The setting range is 48V~58.4V,
the step is 0.4V. Valid only when the battery type is
custom
12
Over-discharge
voltage
[12] 42V Default
Over-discharge voltage. When the battery voltage
is lower than the judgment point, the inverter output
will be turned off after time delay [13]. The setting
range is 40V~46V, the step is 0.4V. Valid only when the
battery type is custom and it is a lithium battery
13
Over-discharge
delay time
[13] 5S Default
Over-discharge delay time. When the battery voltage
is lower than the parameter [12], the Inverter output
will be turned off after delaying the time set by this
parameter. The setting range is 5S~50S, the step is
5S. Valid only when the battery type is custom and it is
a lithium battery
