4 Burner Gas Grill
Parrilla A Gas de 4 Quemadores
OWNER’S MANUAL/MANUAL DEL PROPIETARIO
ASSEMBLY AND OPERATING IN STRUC TIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
WARNING/ADVERTENCIA
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS
AND INSTRUCTIONS ARE IGNORED. READ AND FOLLOW ALL
WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID
PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE
CASO OMISO A ESTAS ADVERTENCIAS E INSTRUCCIONES. LEA
Y SIGA TODAS LAS ADVERTENCIAS E INSTRUCCIONES EN ESTE
MANUAL PARA EVITAR LESIONES PERSONALES, INCLUSO LA
MUERTE, O LOS DAÑOS MATERIALES.
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
WITH GRILL OWNER FOR FUTURE
REFERENCE .
AVISO PARA EL INSTALADOR:
ENTREGUE ESTAS INSTRUCCIONES AL
PROPIETARIO DE LA PARRILLA PARA
REFERENCIA FUTURA.
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
Model/Modelo GAS7480CS
®

Questions and Answers

  • J
    Jon GlennAug 18, 2025
    What to do if my 3 Embers GAS7480CS has a flare-up?
    • T
      Tanya LivingstonAug 18, 2025
      A flare-up on your 3 Embers Grill can be caused by a few things. First, grease buildup on the grill parts is a common culprit; clean all grill parts according to the care and maintenance instructions. Another cause may be excess fat in the meat, so trim the fat before grilling. Finally, excessive cooking temperature can also lead to flare-ups, so adjust the cooking temperature to a lower setting.
  • D
    Destiny HoAug 21, 2025
    Why is my 3 Embers Grill not getting hot enough?
    • L
      Larry WilliamsAug 21, 2025
      If your 3 Embers Grill isn't getting hot enough, the issue might be due to an empty LP gas tank; replace or refill it. Alternatively, the flow-limiting device may have been activated. Try a mini reset by turning the control knobs and LP gas tank valve to the “OFF” position and waiting one minute before relighting the grill per the lighting instructions. If the flames are still too low, perform a full reset by turning everything off, disconnecting the regulator from the propane tank, inspecting the LP cylinder rubber seal, waiting one minute, reconnecting the regulator, performing a leak test, and then lighting the grill.
  • C
    Crystal DavidAug 26, 2025
    What to do if the flame blows out on my 3 Embers Grill?
    • W
      william01Aug 26, 2025
      If the flame on your 3 Embers Grill is blowing out, it could be due to high or gusting winds; avoid using the grill in high winds. It could also be because you're low on LP gas, so replace or refill the LP gas tank. Additionally, burner holes may be obstructed. You can refer to the burner assembly/maintenance instructions for guidance. The flow limiting device may also have tripped, so you should refer to the regulator resetting procedure.
  • D
    Diana RyanAug 28, 2025
    Why is the flame yellow or orange on my 3 Embers GAS7480CS Grill?
    • K
      Keith PonceAug 28, 2025
      A yellow or orange flame on your 3 Embers Grill can be caused by a few things. If it's a new burner, it may have residual manufacturing oils; burn the grill for 15 minutes on high with the lid closed. Another cause could be spider webs or insect nests in the venturi, so clean the venturi and burner assembly. Food residue or grease can also cause this issue, so clean the burner assembly. Finally, poor alignment of the valve to the burner venturi can be the culprit; make sure the burner venturi is properly engaged with the valve.
  • J
    Jessica ClarkeAug 31, 2025
    What causes flashback or melting knobs on my 3 Embers GAS7480CS?
    • C
      Christopher WilkinsonAug 31, 2025
      If you experience flashback (fire in burner tubes) or melting knobs on your 3 Embers Grill, it's likely that the burner and/or burner tubes are blocked. Clean the burners and/or burner assembly to resolve this issue.
  • A
    Ashley ButlerSep 4, 2025
    Why does my 3 Embers GAS7480CS have an irregular flame pattern?
    • J
      James HarrisSep 4, 2025
      An irregular flame pattern on your 3 Embers Grill, where the flame doesn't run the full length of the burner, is often due to clogged or blocked burner ports; clean the burner ports. Alternatively, the air shutter on the burner may need adjustment.
  • C
    chad83Sep 7, 2025
    Why is the inside of my 3 Embers GAS7480CS lid peeling?
    • J
      jamie31Sep 7, 2025
      If the inside of your 3 Embers Grill lid is peeling, it's likely due to baked-on grease buildup that has turned into carbon and is flaking off. Clean the grill thoroughly following the proper care and maintenance instructions.
  • M
    Monica HoodSep 10, 2025
    What to do if there is a grease fire in my 3 Embers Grill?
    • J
      Jacob ReyesSep 12, 2025
      If you have a grease fire in your 3 Embers Grill, it's likely due to grease trapped by food buildup around the burner system. Here's what to do: 1. Turn the control knobs and LP gas tank valve to the “OFF” position. 2. Leave the lid either open or closed and let the fire burn out. If necessary, use a BC type fire extinguisher or baking soda, sand, or dirt to smother the fire. 3. After the grill cools, remove and clean all parts according to the proper care and maintenance instructions.
  • W
    Wendy NelsonNov 14, 2025
    How to fix a burner that won't light on my 3 Embers GAS7480CS Grill?
    • R
      raymarciaNov 14, 2025
      If the burner on your 3 Embers Grill won't light, several factors could be at play. Here's what to check: * Ensure the LP gas tank valve is open and the regulator is securely attached. * Verify that the LP gas tank isn't empty and replace it if needed. * Inspect for gas leaks; if detected, close the LP gas tank valve, wait five minutes, and perform a leak test. * Confirm the coupling nut and regulator are fully connected. * Check for any obstructions in the gas flow and clean the burner assembly, also inspect the hose for bends or kinks. * Make sure the burner is properly seated; if not, reseat it and the valve. * Inspect the venturi for spider webs or insect nests and clean the venturi and burner assembly if necessary. * Clean any clogged or blocked burner ports. * Repl...

3 Embers GAS7480CS Specifications

General IconGeneral
Fuel TypeLiquid Propane
Number of Burners4
BTU48, 000
Ignition SystemElectronic
Side Burner BTU12, 000
Ignition TypeElectronic
MaterialStainless Steel
