Page #65 background image
RJ-45 Pin Assignments 65
Table 11 Pin assignments
Pin Number 10/100 1000
Ports configured as MDIX
1 Receive Data + Bidirectional Data B+
2 Receive Data - Bidirectional Data B-
3 Transmit Data + Bidirectional Data A+
4 Not assigned Bidirectional Data A-
5 Not assigned Bidirectional Data D+
6 Transmit Data Bidirectional Data D-
7 Not assigned Bidirectional Data C+
8 Not assigned Bidirectional Data C-
DUA1745-0AAA02.book Page 65 Monday, August 9, 2004 11:51 AM
