QoS Profile Configuration 225
■ User-based mode: If the source station information (source MAC address,
source IP address or source MAC address + IP address) has been defined in the
ACL which is referenced in the traffic actions, the Switch cannot deliver the
QoS profile; if no source station information is available, the Switch generates a
new ACL by adding the source MAC address and source IP address into the
existing ACL, and then delivers all traffic actions in the QoS profile to the user
port.
■ Port-based mode: The Switch delivers the traffic actions in the QoS profile
directly to the user port.
Perform the following configuration in Ethernet Port View.
Tab le 251 Configuring Profile Application Mode
By default, port-based mode is enabled on the port.
Applying QoS Profile to
the Port
With this configuration, you can apply all traffic actions in the QoS profile to the
current port.
In System View
In System View, you can apply the QoS profile to one or more consecutive ports.
Tab le 252 Applying QoS Profile to the Port in System View
In Ethernet Port View
In Ethernet Port View, you can only apply the QoS profile to the current port.
Tab le 253 Applying QoS Profile to the Port in Ethernet Port View
You cannot delete the specific QoS profile once you apply it to the port.
Displaying and Debugging QoS Profile Configuration
Use the display command in any view to check the configuration result of the
QoS profile.
Operation Command
Configure the user-based mode on the port qos-profile user-based
Restore the default (port-based) mode on
the port
undo qos-profile user- based
Operation Command
Apply the QoS profile
to the port
apply qos-profile
profile_name
interface {
interface_name
|
interface_type interface_num
} [
to interface {
interface_name
|
interface_type
interface_num
} ]
Remove the
configuration
undo apply qos-profile
profile_name
interface {
interface_name
|
interface_type interface_num
} [
to interface {
interface_name
|
interface_type
interface_num
} ]
Operation Command
Apply the QoS profile to the port apply qos-profile
profile_name
Remove the configuration undo apply qos-profile
profile_name
