224 CHAPTER 8: ACL CONFIGURATION
Configuring QoS Profile
You must first define ACLs for the traffic actions before adding the actions to the
QoS profile.
Entering QoS Profile View
To configure the QoS profile, you must first enter QoS profile view.
Perform the following configuration in System View.
Table 249 Entering QoS Profile View
You cannot delete the specific QoS profile which has been applied to the port.
Adding/Removing Traffic Action to a QoS Profile
From the QoS Profile View, you can configure the QoS actions for current QoS
profile. The maximum action numbers in one QoS profile is 32.
Perform the following configuration in QoS Profile View.
Table 250 Adding/Removing Traffic Action to QoS Profile
You cannot remove the packet filtering, traffic policing or preference replacing
action from the QoS profile which has been applied to the port.
Configuring Profile
Application Mode
After you configure the QoS profiles and the user passes the authentication, the
Switch will deliver the right profile dynamically to the port from which the user is
accessed. The QoS profile can be delivered to the port in these different modes:
Operation Command
Enter QoS profile view qos-profile
profile-name
Delete the QoS profile undo qos-profile
profile-name
Operation Command
Add packet filtering
action
packet-filter inbound ip-group
acl_number
[ rule
rule
[ link-group
acl_number
rule
rule
] ] |
link-group
acl_number
[ rule
rule
] }
Add traffic policing
action
traffic-limit inbound ip-group
acl_number
[ rule
rule
[ link-group
acl_number
rule
rule
] ] |
link-group
acl_number
[ rule
rule
] }
target_rate
[
exceed
action
]
Add preference
replacing action
traffic-priority inbound { ip-group
acl_number
[
rule
rule
[ link-group
acl_number
rule
rule
] ] |
link-group
acl-number
[ rule
rule
] } { { dscp
dscp_value
| ip-precedence {
pre_value
| from-cos
} } | {
pre_value
| from-ipprec } |
local-precedence
pre_value
}*
Remove packet
filtering action
undo packet-filter inbound { ip-group
acl_number
[ rule
rule
[ link-group
acl_number
rule
rule
] ] |
link-group
acl_number
[ rule
rule
] }
Remove traffic policing
action
undo traffic-limit inbound { ip-group
acl_number
[
rule
rule
[ link-group
acl_number
rule
rule
] ] |
link-group
acl_number
[ rule
rule
] }
Remove preference
replacing action
undo traffic-priority inbound { ip-group
acl_number
[ rule
rule
[ link-group
acl_number
rule
rule
] ] | link-group
acl_number
[ rule
rule
] }
