Product Overview
1 Clipping indicaon LED – Le channel
5 Clipping indicaon LED – Right channel
2 RCA input indicaon LED
4 XLR input indicaon LED
3 Mul-funcon KEY – Power on & o, input selecon, volume control
● Short press – Input source switch between RCA and XLR
● Long press (above 2 Seconds) – Power o (standby mode can wake up by audio or 12V trigger)
6 Balance XLR/6.35mm TRS combo input – Right channel
7 Balance XLR/6.35mm TRS combo input – Le channel
8 Single-end RCA input – Le channel
14 Single-end RCA input – Right channel
9 RCA Gain seng (LOW=25dB,HIGH=28.5dB)
12 Volume control seng
10 R+ speaker output: negave output of Right channel
15 R- speaker output: negave output of Right channel
11 L+ speaker output: negave output of Le channel
16 L- speaker output: negave output of Le channel
13 DC Power supply input
1 2 3 4 5
6 7 8 9 10 11 12 13
14 15 16
